Boost Your PCB Reliability: The SI/PI Design Playbook
Share
Over the past few years, electronic devices have become increasingly compact, faster, and capable of operating at higher frequencies. This evolution has placed greater demands on the performance of printed circuit boards (PCBs), pushing design requirements to new levels of precision.
Two critical aspects that engineers must consistently address are Signal Integrity (SI) and Power Integrity (PI). While these may seem like separate concerns at first, they are deeply interconnected. A disruption in either can compromise the entire system’s stability, making it essential to consider both in tandem during the design process.
What is SI (Signal Integrity)?
SI is the concept of evaluating whether a signal is correctly transmitted from the sender to
the receiver.
Typical challenges include:
• Reflection: Signal reflection due to impedance mismatch
• Crosstalk: Unwanted coupling between adjacent traces
• Skew: Length mismatch in differential pair routing
• Jitter: Temporal fluctuations in clocks or signals
If SI is not maintained, signals can become distorted, data may be misinterpreted, and
system errors can occur.
What is PI (Power Integrity)?
PI is the concept of evaluating whether the power supplied to devices is stable.
Key points include:
• Voltage Drop (IR Drop): Voltage reduction due to resistance in copper traces or vias
• Ground Bounce: Fluctuations in the ground reference due to simultaneous switching
• Power Noise: Degradation of power quality due to ripple or resonance
• Insufficient Decoupling: Power fluctuations caused by poor capacitor placement
If PI is compromised, LSIs (large-scale integrations) and high-speed ICs (integrated circuits) may become unstable, leading to malfunctions or even clock stoppage.
SI and PI are Two Sides of the Same Coin
In actual PCB design, SI and PI are not independent; they affect each other.
• Power noise (a PI issue) can be superimposed on clock signals, degrading SI.
• Poor impedance control in signal traces (an SI issue) can increase the burden on
power lines, worsening PI.
Thus, considering only one is not sufficient; both must be optimized simultaneously.
Design Strategies for Ensuring Signal and Power Integrity
SI Measures:• Impedance-controlled routing
• Matching lengths of differential pair traces
• Proper layer structure and return path design
PI Measures:
• Securing power/ground planes
• Proper placement and selection of decoupling capacitors
• Designing trace width and via size according to current capacity
Additionally, using EDA tools for SI/PI simulation in advance allows visualization of
potential issues during the design stage, preventing rework.
